公司基本資料信息
|
||||||||||||||||||||||||||||||||
|
名稱Name |
ZH607/607L |
|
|
應用Application |
裝配、上下料Assembly/Load and Upload Material |
|
|
軸數 Axes |
6 |
|
|
負載Payload |
7Kg |
|
|
安裝環境 Installation Environment |
安裝方式Installation |
地面 Ground；側裝；倒裝 |
|
溫度Temperature |
0-45℃ |
|
|
濕度Humidity |
20-80%RH（無結霜Frost Free） |
|
|
工作半徑Working Range |
780/900mm |
|
|
重復定位精度Positioning Repeatability |
±0.05mmm |
|
|
防護等級Protection Level |
IP54 |
|
|
自重Weight |
30/32Kg |
|
|
運動參數 |
運動范圍Motion Range |
最大速度Max Speed |
|
J1 |
±170° |
370°/S |
|
J2 |
±110° |
370°/S |
|
J3 |
+40°/-220° |
430°/S |
|
J4 |
±360° |
300°/S |
|
J5 |
±185° |
460°/S |
|
J6 |
±360° |
600°/S |
ZH607/607L配置清單Configuration List
|
伺服電機Servo Motor |
諧波減速機Harmonic Drive |
控制器Controller |
|
|
品牌Brand |
禾川HCFA |
來福LAIFUAL |
卡諾普CRP |
