量 程 Measuring Range -0.1~ 200MPa
工作環境 Operating Environment -20?C~75?C, ≤85%RH
精 度 Accuracy 0.1% FS; 0.25% FS; 0.5% FS
儲存環境 Storage Environment -40?C~85?C, ≤95%RH
供電電壓 Power Supply
傳感器Transducer: ?5?10VDC
安全過載能力 變送器 Transmitter: +9 ~ 36VDC Safe Over Load 150%
輸出信號 Output Signal 1.5mV/V, 2mV/V,
4-20mA, 0-20mA, 0-10V, 0-5V
極限過載能力 Ultimate overload 250%
零點誤差 Zero Error ?0.5% FS
溫度漂移 Temperature Shift 0.03%FS/?C
滿度誤差　Full Scale Error ?1.0% FS
長期穩定性 Long Stability ?0.2%FS/year
補償溫度 Compensate Temperature -10?C?70?C
外殼材料 Housing Material 316 Stainless steel 不銹鋼
可選接口螺紋 Process connection M20×1.5, M12×1, M10×1 ,1/4NPT, G1/2, G1/4 or as custom 或客制化
電器連接 Electrical Connection Direct cable 1m ; Hirschman connector or as request
主要應用 Application
氣/液壓力測控系統、工業設備、醫療設備、制冷設備、恒壓供水、過程控制等領域
Process control system, liquid level measurement, gas compressors, lubrication systems, natural gas production,
chemical processing, waste water treatment, pulp & paper processing, oil production, recovery and others
