The product is available in two sizes: a 42mm square installation flange and 60mm square installation flange.
The integrated design of the driver and motor enables a more compact installation space and less wiring, and this is combined with a selection function for matching the operation mode to the application for greater operating convenience.
 |
A driver incorporating a motion control function needed for driving a motor and a 2-phase stepping motor were integrated into a single unit for enabling a more compact installation space and less wiring.
| Model No. | DB21M142S-01 | DB22M162S-01 | |
|---|---|---|---|
| Motor size | 42mm square ~70mm | 60mm square~88mm | |
| Weight | 0.5kg | 0.86kg | |
| Holding torque | 0.26 N?m | 1.05 N?m | |
| Input power | DC24V±10% | ||
| Operating temperature | 0℃~+40℃ | ||
| Display | LED 7-segment display | ||
| Protection function | Drive overheating, Overcurrent | ||
| Basic step angle | 0.9°/step | ||
| Control mode | Command pulse mode | Max. command pulse: 300kpps | |
| Step angle selection: 16 resolution types (1/1,1/2,1/2.5,1/4,1/5,1/8,1/10,1/20,1/25,1/40,1/50, 1/80,1/100,1/125,1/200,1/250) |
|||
| General-purpose I/O mode | Number of programs: Up to 16 | ||
| Serial mode | Compliant with RS-485, half-duplex asynchronous communication, Communication speedF9600/38400bps |
||
| Output signal | Alarm output, BUSY output, phase zero-point monitor | ||
| Safety Standards | UL, CE marks | ||
NB: This is a RoHS-compliant product. (RoHS is an abbreviation for Restriction of Hazardous Substances, and it refers to a directive issued by the European Parliament and European Council for restricting the use of specific hazardous substances contained in electronic and electrical equipment.)
Semiconductor manufacturing equipment, chip mounters, surveillance cameras, belt conveyor equipment,
general industrial machinery, replacement of DC brushless motors and induction motors
