AB

是否進口

是

功率

0.1-500KW

訂貨號

ECSAG803616

物料

ABJLBPQ96206

有無認證

3C

系列

PowerFlex

是否跨境

否

電壓

AC220-600V

運用

風機水泵 紡織等

可售賣地

全國

型號

25A-A4P8N114

25A-A4P8N114變頻器美國AB羅克韋爾變頻器體驗硬實力



PowerFlex 523 交流變頻器

PowerFlex? 523 交流變頻器經濟高效，是單機設備的理想選擇。這款變頻器采用創新的模塊化設計，安裝和配置簡便、快捷。此外，還提供 USB 編程、應用項目特定的配置以及靈活的安裝選項。PowerFlex 523 交流變頻器具有 100 600V 全面電壓等級，提供 0.2 22 kW (0.25 30 Hp) 的額定功率。它們支持各種電機控制，占地面積小，可以在高達 70 °C (158 °F) 的溫度下運轉。

特性

額定功率為 0.2-22 kW / 0.25-30 Hp，適合 100-600V 的全球電壓

采用模塊化設計，帶有創新的可拆卸控制核心，支持同時進行安裝和軟件配置

提供廣泛的電機控制，包括電壓/頻率、無傳感器矢量控制以及帶經濟模式的無傳感器矢量控制

在電流降額并使用控制模塊風扇套件時，可在最高 70°C (158°F) 的環境溫度范圍內運行

提供肩并肩并排安裝，變頻器頂部和底部保留 50mm (1.96 in) 氣流間隙

通過集成的 RS485/DSI 端口支持低成本聯網

25A-A011N104    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 3 HP, 2.2 kW Normal Duty; 3 HP, 2.2 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter

25A-A011N114    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 3 HP, 2.2 kW Normal Duty; 3 HP, 2.2 kW Heavy Duty, frame B, IP20 NEMA / Open Type, Filter

25A-A1P6N104    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 0.25 HP, 0.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-A1P6N114    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 0.25 HP, 0.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-A2P5N104    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-A2P5N114    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-A4P8N104    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-A4P8N114    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-A8P0N104    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 2 HP, 1.5 kW Normal Duty; 2 HP, 1.5 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter

25A-A8P0N114    PowerFlex 523 AC Drive, 240 VAC, 1 Phase, 2 HP, 1.5 kW Normal Duty; 2 HP, 1.5 kW Heavy Duty, frame B, IP20 NEMA / Open Type, Filter

25A-B011N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 3 HP, 2.2 kW Normal Duty; 3 HP, 2.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-B017N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 5 HP, 4 kW Normal Duty; 5 HP, 4 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter

25A-B024N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 7.5 HP, 5.5 kW Normal Duty; 7.5 HP, 5.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, No Filter

25A-B032N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 10 HP, 7.5 kW Normal Duty; 10 HP, 7.5 kW Heavy Duty, frame D, IP20 NEMA / Open Type, No Filter

25A-B048N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 15 HP, 11 kW Normal Duty; 10 HP, 7.5 kW Heavy Duty, frame E, IP20 NEMA / Open Type, No Filter

25A-B062N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 20 HP, 15 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame E, IP20 NEMA / Open Type, No Filter

25A-B1P6N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 0.25 HP, 0.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-B2P5N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-B5P0N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-B8P0N104    PowerFlex 523 AC Drive, 240 VAC, 3 Phase, 2 HP, 1.5 kW Normal Duty; 2 HP, 1.5 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-D010N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 5 HP, 4 kW Normal Duty; 5 HP, 4 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter

25A-D010N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 5 HP, 4 kW Normal Duty; 5 HP, 4 kW Heavy Duty, frame B, IP20 NEMA / Open Type, Filter

25A-D013N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 7.5 HP, 5.5 kW Normal Duty; 7.5 HP, 5.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, No Filter

25A-D013N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 7.5 HP, 5.5 kW Normal Duty; 7.5 HP, 5.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, Filter

25A-D017N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 10 HP, 7.5 kW Normal Duty; 10 HP, 7.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, No Filter

25A-D017N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 10 HP, 7.5 kW Normal Duty; 10 HP, 7.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, Filter

25A-D024N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 15 HP, 11 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame D, IP20 NEMA / Open Type, No Filter

25A-D024N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 15 HP, 11 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame D, IP20 NEMA / Open Type, Filter

25A-D030N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 20 HP, 15 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame D, IP20 NEMA / Open Type, No Filter

25A-D030N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 20 HP, 15 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame D, IP20 NEMA / Open Type, Filter

25A-D037N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 25 HP, 18.5 kW Normal Duty; 20 HP, 15 kW Heavy Duty, frame E, IP20 NEMA / Open Type, Filter

25A-D043N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 30 HP, 22 kW Normal Duty; 25 HP, 18.5 kW Heavy Duty, frame E, IP20 NEMA / Open Type, Filter

25A-D1P4N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-D1P4N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-D2P3N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-D2P3N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-D4P0N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 2 HP, 1.5 kW Normal Duty; 2 HP, 1.5 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-D4P0N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 2 HP, 1.5 kW Normal Duty; 2 HP, 1.5 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-D6P0N104    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 3 HP, 2.2 kW Normal Duty; 3 HP, 2.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-D6P0N114    PowerFlex 523 AC Drive, 480 VAC, 3 Phase, 3 HP, 2.2 kW Normal Duty; 3 HP, 2.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, Filter

25A-E012N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 10 HP, 7.5 kW Normal Duty; 10 HP, 7.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, No Filter

25A-E019N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 15 HP, 11 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame D, IP20 NEMA / Open Type, No Filter

25A-E022N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 20 HP, 15 kW Normal Duty; 15 HP, 11 kW Heavy Duty, frame D, IP20 NEMA / Open Type, No Filter

25A-E027N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 25 HP, 18.5 kW Normal Duty; 20 HP, 15 kW Heavy Duty, frame E, IP20 NEMA / Open Type, No Filter

25A-E032N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 30 HP, 22 kW Normal Duty; 25 HP, 18.5 kW Heavy Duty, frame E, IP20 NEMA / Open Type, No Filter

25A-E0P9N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-E1P7N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-E3P0N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 2 HP, 1.5 kW Normal Duty; 2 HP, 1.5 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-E4P2N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 3 HP, 2.2 kW Normal Duty; 3 HP, 2.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-E6P6N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 5 HP, 4 kW Normal Duty; 5 HP, 4 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter

25A-E9P9N104    PowerFlex 523 AC Drive, 600 VAC, 3 Phase, 7.5 HP, 5.5 kW Normal Duty; 7.5 HP, 5.5 kW Heavy Duty, frame C, IP20 NEMA / Open Type, No Filter

25A-V1P6N104    PowerFlex 523 AC Drive, 120 VAC, 1 Phase, 0.25 HP, 0.2 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-V2P5N104    PowerFlex 523 AC Drive, 120 VAC, 1 Phase, 0.5 HP, 0.4 kW Normal Duty; 0.5 HP, 0.4 kW Heavy Duty, frame A, IP20 NEMA / Open Type, No Filter

25A-V4P8N104    PowerFlex 523 AC Drive, 120 VAC, 1 Phase, 1.0 HP, 0.75 kW Normal Duty; 1.0 HP, 0.75 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter

25A-V6P0N104    PowerFlex 523 AC Drive, 120 VAC, 1 Phase, 1.5 HP, 1.1 kW Normal Duty; 1.5 HP, 1.1 kW Heavy Duty, frame B, IP20 NEMA / Open Type, No Filter
