STE4,5B0.37/6德國施耐德風門執行器
上海益斯特 130 6167 0309

STE系列由模擬信號 （電流或電壓) 進行控制?？赏ㄟ^模擬信號設置軸的旋轉角度。操作范圍，可以自由地在0和90°之間的定義。在界定的工作范圍內，可以選擇任何的旋轉角度。根據版本，
設定值可以設置作為一個從0到10V的電壓信號或從4至20毫安的電流信號。運行范圍的限制也可以由兩個極限開關得到保障。新STE數字式已經上市，供電電壓為24V。
STE4,5B0.37/6德國施耐德風門執行器
上海益斯特 130 6167 0309

You can use the actuators from Berger Lahr to position flaps, valves or slides with great precision. Inside the compact servo drive housing there is a motor, a gearbox and a control unit.
There is a choice of three actuator types to solve your positioning problems: STM, STA and STE.
Actuators of type STE are controlled by analogue signals (current or voltage). The angle of rotation of the shaft can be set via analogue signals. The operating range can be freely defined
between 0 and 90×. Any angle of rotation can be selected within the defined operating range. Depending on the version, the setpoint can be set as a voltage from 0 to 10 V or as a current
from 4 to 20 mA. The limits of the operating range can also be safeguarded by two limit switches.
